GARSON | D.A.D LUXURY CENTER DYNAMIC WOOFER

* Image shows ( left : Type Crocodile / right : Type Vega · Black, with blue LED illuminated. )

* Type Crocodile / Amp (LUX-S4000)

8 inch Non-Press Paper Cone Speaker & 420w MOS-FET Amplifier.

This 8 inch Non-Press Paper Cone speaker and external 420 watt MOS-FET* amplifier reach ultimate dimensions, by producing both good sharp and soft sounds, *(metal oxide semiconductor field effect transistor amp) Installing the unit in the center of the vehicle produces direct, dynamic sharps and quick lows.

Producing a Luxurious Night Scene

These luxurious speakers are treated with Blue LED Illumination and 4 Swarovski Crystals along the frames, to help create the perfect night atmosphere for you and that special person. (Equipped with stand-alone line for illumination)

Layout Free Speakerbox

The included velcro tape and curved shape of the speaker box underbody makes it easy to install, virtually anywhere. Connect to your car's audio (factory or after-market) via the RCA connector or speaker wire.

Optional part

By connecting the unit to our optional Luxury Lighting System Controller, you can control and set the lighting sequence to your preferences.

> detail : LUXURY LIGHTING SYSTEM CONTROLLER

* Image shows ( with blue LED illuminated. )

Garson does not sell directly to customers abroad.
For sales and information about our products, please contact one of the following international Garson dealers.

D.A.D DEALER NETWORK

D.A.D LUXURY CENTER DYNAMIC WOOFER

Price --,--- JPY

■Item No. / Design patterns (Material colors)

• SA448-01 / Leaf (Black)  • SA448-02 / Crocodile (Black)
• SA448-03 / Leather *simple emboss (Black)
• SA448-04 / Vega (Black)  • SA448-05 / Vega (Antique brown)
• SA448-06 / Monogram (Black)  • SA448-07 / Monogram (Beige)
• SA448-08 / Monogram Leather (Black)
• SA448-09 / Monogram Leather (Beige)

■Size (Circumference)

· BOX : Height 240mm, Width 280mm, Length 260mm
· Amp : Height 50mm, Width 225mm, Length 165mm

■SWAROVSKI ELEMENTS Color : Crystal

* Fittings & Accessories

RCA Cable, Power Cable w/ Connector, Necessary Installation Fittings.

【 Content 】

Velcro tape for main unit, a BASS controller, a Hi/Lo converter, power cable, gland cable, RCA cable, remote cable, speaker cable, BASS controller cable, LED power cable, fuse holder, fuse, terminal, tie raps, corrugate tubing, hexagonal wrench (large & small)

▼ Parameter

●Amp
Rated power	220W	Signal-to-noise ratio	80dB
Maximum output	400W	Cross over frequency (L.P.F)	50Hz - 250Hz
Standby current	500mA	Bass boost	0 - 12dB
Maximum operating current	30A	Input sensitivity	0.2A - 4.0A

●Speaker : 8 inch (20cm)
Rated input power	100W	Edge	0.8 inch foam
Maximum input	350W	Basket	Steel
Magnet	30 oz strontium	Output sound pressure level	88dB (1m/1W)
Voice coil	1.5 inch, 4 layers
Cone	Non-press paper cone

■ Installation Samples ( with blue LED illuminated ) * Units are universal and not for a particular model car.

· MH23 WAGON-R ( Front Seat Installation )

· L175/185 MOVE ( Front Seat Installation )

· ACR/GSR50,55 ESTIMA ( Front Seat Installation )

· MH WAGON-R ( Front Seat Installation )

· ANH/GGH2# ALPHARD&VELLFIRE ( Back Seat Installation )

· RB1,2 ODYSSEY ( Back Seat Installation )

· QNC20,25 bB ( Back Seat Installation )

LUX-S4000 420W HIGH POWER MOS-FET AMPLIFIER

The High-Power, LUX-S4000 Amplifier was developed to fulfill D.A.D's insistence of both sharp and powerful bass. This High-Power (420w max) MOS-FET amplifier delivers consistant power and reduced interference noise, for a smooth, non-distorted high-quality bass.
Connector illuminates blue when power is on.

CONTROLLER

Because the unit comes with a 5 meter wired controller, the sub woofer can be adjusted from the drivers seat.

SWAROVSKI ELEMENTS

The center is garnished with SWAROVSKI ELEMENTS , fused with the blue illumination emitted from the speaker area, to create a fascinating beauty that will charm everyone.

U-shaped underside and velcro for easy installation.

Making the underpart of the box U-shaped allows for a good fit for most vehicles, while the included velcro tape locks it into place.

D.A.D engraved studs

There are a total of 8 D.A.D engraved studs along both sides of the box. The shiny chrome coating and D.A.D logo combination, make sure everyone recognizes the D.A.D presence.

LUXURY LIGHTING SYSTEM CONTROLLER

Price --,--- JPY

By connecting the unit to our optional Luxury Lighting System Controller, you can control and set the lighting sequence to your preferences.
Also, the Luxury Lighting System Controller includes a Dance Mode function which makes the light dance to the sound of your music.
